Part Number: 3SW/LM3 - - 1T1



PRODUCT SPECIFICATION

Rating

5A @250V AC / 5A @125V AC

Degree of temperature

85° C

Operating force

0.5N

Contact resistance

50 mOhm max. initial

Insulation resistance

100 MOhm min @500V DC

Test voltage

1000V AC for 1 minute (between terminals of the same polarity)

2000V AC for 1 minute (between current-carrying metal parts and case, and between each terminal and non-current-carrying metal parts)

Vibration resistance

1.5mm @10~55Hz double amplitude

Electrical life

500,000 cycles min

Safety approvals

UL, CUL, VDE
